Zampa Aluminium, located in Canberra, Australia, stands out as a top-notch manufacturer and supplier of high-quality Aluminium 5083 Circles. Known for their precision engineering and exceptional craftsmanship, the company guarantees that every circle adheres to strict industrial standards. Aluminium 5083 is highly regarded for its remarkable corrosion resistance, impressive strength, and excellent performance in marine and coastal settings. Zampa Aluminium’s 5083 Circles are crafted to precise specifications, making them perfect for demanding applications. By merging cutting-edge production methods with thorough quality control, Zampa Aluminium delivers durable, reliable, and high-performance aluminium solutions for clients in the marine, automotive, aerospace, and industrial sectors.
Aluminium 5083 Circles mainly consist of aluminium with magnesium (4–4.9%), manganese (0.4–1%), and small amounts of chromium (0.05–0.25%). This unique blend offers outstanding corrosion resistance, especially in seawater and tough environments. In terms of mechanics, 5083 Circles showcase a tensile strength ranging from 275 to 350 MPa and a yield strength between 125 and 200 MPa, depending on the temper. The alloy also boasts impressive ductility and formability, with elongation values between 12% and 18%. Its lightweight nature and high strength-to-weight ratio make it perfect for lightweight structures, while the addition of chromium and manganese enhances resistance to strain hardening and boosts overall durability.
| Specifications | ASTM B209 / ASME SB209 |
|---|---|
| Temper | O,H12,H14,H16,H18,H19,H22,H24 |
| Thickness | 1 Mm To 100 mm |
| Diameter | Upto 2000 mm |
| Circle Diameter | 3″ DIA up to 38″ DIA 1500 lbs max |
| Circles Form | Hot Rolled Circles, Cold Rolled Circle, Proof Machined Circles |
| Finish | Mill, Customer specific finish |
| Aluminum Circle Coating | PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating |
| Al | Si | Fe | Cu | Mn | Cr | Mg | Ti | Zn | Other Each | Others Total |
| Bal | 0.40 max | 0.40 max | 0.10 max | 0.40 / 1.0 | 0.05 / 0.25 | 4.0 / 4.90 | 0.15 max | 0.25 max | 0.05 max | 0.15 max |
| Proof Stress | Tensile Strength | Hardness Brinell | Elongation |
| 125 Min MPa | 275 – 350 MPa | 75 HB | 12 Min % |
| European Standard | GERMANY | UNS | WERKSTOFF NR. |
| EN AW-5083 A | Al-Mg-5 | A95083 | 3.3547 |
Aluminium 5083 Circles find extensive use in the marine, automotive, aerospace, and industrial sectors due to their superior corrosion resistance and strength. In the marine industry, they are ideal for shipbuilding, boat hulls, and offshore structures that face seawater exposure. In aerospace, they are used for lightweight aircraft components, fuel tanks, and structural parts that require high strength-to-weight ratios. In automotive and industrial manufacturing, 5083 Circles are utilized for pressure vessels, storage tanks, and transportation equipment. Their excellent weldability further enhances their appeal across various applications.
Yes, we offer custom sizes for Aluminium 5083 Circles to meet specific project needs. Our team at Zampa Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@zampaaluminium.com
Aluminium 5083 Circles find extensive use in the marine, automotive, aerospace, and industrial sectors due to their superior corrosion resistance and strength. In the marine industry, they are ideal for shipbuilding, boat hulls, and offshore structures that face seawater exposure. In aerospace, they are used for lightweight aircraft components, fuel tanks, and structural parts that require high strength-to-weight ratios. In automotive and industrial manufacturing, 5083 Circles are utilized for pressure vessels, storage tanks, and transportation equipment. Their excellent weldability further enhances their appeal across various applications.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
